Welcome to a better flash architecture Smart AFA choice for modern workloads provides self-optimizing performance, federated scale and mobility, all-inclusive software value.
Maximum thermal output/heat dissipation:
SC7020F: 5,760 BTU per hour
SC5020F: 5,770 BTU per hour (1378W supply option) or 5,760 BTU per hour (1485W supply option)
Go to Specification Sheet
Controllers:
2 hot-swappable per chassis (active/active)
Processors:
SC7020F: Dual Intel® Xeon® Processors, E5-2628 v3 2.5GHz, 8 cores / SC5020F: Single Intel® Xeon® Processor E5-2630 v3, 2.4GHz, 8 cores
Internal storage capacity:
30 x 2.5” drive bays
System Memory:
SC7020F: 256GB per array (128GB per controller) SC5020F: 128GB per array (64GB per controller)
Supported expansion enclosures:
Dell SC420F: 24 x 2.5” drive bays (12Gb SAS)
Maximum drive count:
SC7020F: 606 drives per array / SC5020F: 222 per array (with optional expansion enclosures)
